StufiKlapp ladder for pits V3 acc. to EN 81-20. NEW! With simplified wall suspension!


StufiKlapp EN 81-20

New wall suspension

and storing position

Wall suspension StufiKlapp EN 81-20

In the new version of the StufiKlapp the control switch is directly integrated in the wall suspension. The ladder is simply hooked into the suspension by means of bolts, so that the switch engages and is actuated automatically.

The external dimensions in storing position are only 120 x 126mm.

Dimensional drawing

Wall with control switch without ladder and with ladder

Functional description

Ladder unfolded and ladder halfway unfolded

Ladder folded, in storing position and fixation sheet

The ladder StufiKlapp is a switch-monitored foldable step ladder, which is suitable for shaft pits.
As opposed to other pit ladders, the StufiKlapp offers the following advantages: It is much shorter, as it is not required for step ladders of this type that they jut out 1.10m above the access point. As the StufiKlapp juts out very little, it is not necessary to fix the lower end of the ladder to prevent it from tilting.
Also the StufiKlapp occupies very little space with 120 x 126mm in the folded position. Thus there is more space in the pit. The two handles on the side avoid the danger of squeezing fingers at folding and unfolding the ladder and they provide a simple handling.
The new, improved version of the StufiKlapp corresponds to the EN 81-20 and has a Type Examination Certificate from the Liftinstituut.
The ladder is available in four different sizes.

Safety when descending into the pit

The ladder StufiKlapp is simply leaning against the lowest shaft access point with the fixation sheet.
Non-skip rubber coating on the fixation sheet and on the ladder feet inhibits lateral shifting. In the ladder stiles there are pre-drilled holes, so that the fixation sheet can be adjusted according to the local pit depth.

Comparison of the ladder types

Rung ladders and step ladders

Rungs have a general width of 30mm. Descending safely is only possible when the ladder exceeds at least 1.10m above the exit point.

Steps have a minimum width of 80mm and are almost horizontal. They assure a safe descending. According to the state-of-the-art it is not necessary that the ladder exceeds above the exit point, if the door frame can be used as support. If the door frame is not suitable as a handle, e.g. in the case of hinged doors, a separate handhold needs to be mounted at the shaft wall.

Ladder-ACCESSORY-SET-E, optional

Handhold for descending into pit, optional

Scope of delivery and mounting example

For uneven and oily pit floors, we recommend the installation of an additional floor fixation clamp with levelling sheets. Scope of delivery: 1 piece fixation clamp, 3 pieces levelling sheets and 1 fastening kit.

Scope of delivery

If the door frame is not suitable as a handle, e.g. in the case of hinged doors, a separate handhold art.no. 078341 for descending into the pit needs to be mounted at the shaft wall. For wall fastening, incl. dowels and screws, mounting depth 50mm.

Products

Description
Stufiklapp 89 EN 81-20 V3 (077020)
Pit ladder Stufiklapp 89 EN 81-20 V3, ladder length 96cm, suitable for pits: 50cm - 89cm. Scope of delivery: one folding step ladder complete with monitoring switch, accessories and mounting instruction. According to EN 81-20 and EN131-2.
Stufiklapp 117 EN 81-20 V3 (077021)
Pit ladder Stufiklapp 117 EN 81-20 V3, ladder length 126cm, suitable for pits: 60cm - 117cm. Scope of delivery: one folding step ladder complete with monitoring switch, accessories and mounting instruction. According to EN 81-20 and EN 131-2.
Stufiklapp 145 EN 81-20 V3 (077022)
Pit ladder Stufiklapp 145 EN 81-20 V3, ladder length 156cm, suitable for pits: 88cm - 145cm. Scope of delivery: one folding step ladder complete with monitoring switch, accessories and mounting instruction. According to EN 81-20 and EN 131-2.
Stufiklapp 175 EN 81-20 V3 (077023)
Pit ladder Stufiklapp 175 EN 81-20 V3, ladder length 185cm, suitable for pits: 88cm - 145cm. Scope of delivery: one folding step ladder complete with monitoring switch, accessories and mounting instruction. According to EN 81-20 and EN 131-2.
Ladder -ACCESSORY-SET-E (078599)
Ladder -ACCESSORY-SET-E for Stufiklapp, fixation clamp with levelling sheets for the floor. Scope of delivery: 1 piece fixation clamp, 3 pieces levelling sheets and 1 fastening kit.
